CNC Milled Project Highlights
- Product Name
Propel Plate
- Product Description
This propel plate is used in an adjustment lever.
- Capabilities Applied/Processes
Primary:
Saw Cutting
EDM Machining
CNC MillingSecondary:
Deburring
Part Marking
Drilling / Tapping
Zinc Plating
- Equipment Used to Manufacture Part
Band Saw
Haas Vertical Machining Center
EDM
Part Marker
- Overall Part Dimensions
Length: 3.425″
Width: 0.788″
Height: 0.315″ + 0.000 / – 0.004
- Tightest Tolerances
+ 0.000″ / – 0.004″
Angular: ± 1°
- Material Used
1018 Steel
- Material Finish
Zinc Plated
- Thickness: 0.00015″ minimum. Trivalent Chrome
- Color: Silver
- In Process Testing/Inspection Performed
Dimensional Inspection
Gage Inspection
Visual Inspection
- Industry for Use
Heavy Equipment
- Volume
190
- Delivery/Turnaround Time
4 Weeks
- Delivery Location
United States
- Standards Met
Customer Specifications, 2D CAD Drawing
