Multi-Spindle Screw Machining Project Highlights
- Product Name
Support Assembly
- Product Description
This support assembly is used within a control panel support.
- Capabilities Applied/Processes
Primary:
Multi-Spindle Screw Machining
Assembly
EtchingSecondary:
Drilling/Tapping
Part Washing
- Overall Part Dimensions
4.5 inches
- Torque Specifications
221 ± 52 lb. in.
- Material Used
7/8″ Hex 1018 Steel
- In Process Testing/Inspection Performed
Static Torque Inspection
Dimensional Inspection
Visual Inspection
- Industry for Use
Heavy Equipment
- Volume
10,000
- Delivery/Turnaround Time
4 Weeks
- Delivery Location
United States
- Standards Met
Customer Specifications, 2D CAD Drawing
